TLP293(GRL-TPL,E Toshiba Semiconductor and Storage TLP293(GRL-TPL,E label picture TLP293(GRL-TPL,E label picture 2 TLP293(GRL-TPL,E real image
TLP293(GRL-TPL,E Toshiba Semiconductor and Storage TLP293(GRL-TPL,E label picture TLP293(GRL-TPL,E label picture 2 TLP293(GRL-TPL,E real image
Same model may have multiple batches, images only for reference.

TLP293(GRL-TPL,E

Part No TLP293(GRL-TPL,E
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler DC-IN 1-CH Transistor DC-OUT 4-Pin SO T/R / OPTOISOLATOR 3.75KV TRANS 4-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 500μA
Maximum DC Current Transfer Ratio 200% @ 500μA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 4-SO
Win Source Part Number 1108906-TLP293(GRL-TPL,E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name TLP293
ECCN EAR99
Country of Origin Thailand
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian TLP293(GRL-TPL,E CAD Model

Description

The TLP293(GRL-TPL,E) is a transistor output optocoupler manufactured by Toshiba Semiconductor and Storage.

  • Isolation Voltage: 3750Vrms
  • Input Type: DC
  • Output Type: Transistor
  • Operating Temperature: -55°C to 125°C
  • Minimum DC Current Transfer Ratio: 100% @ 500μA
  • Maximum DC Current Transfer Ratio: 200% @ 500μA
  • Switching Turn-On Time: 3μs
  • Switching Turn-Off Time: 3μs
  • Rise Time: 2μs
  • Fall Time: 3μs
