The TEN 15-2412 is a 15 Watt isolated DC/DC converter module manufactured by TRACO Electronic AG. It is designed for a wide range of applications where a regulated DC voltage is required from a DC source. It features a wide input voltage range, regulated output voltage, and input/output isolation.

Applications

• Industrial automation and control systems.
• Mobile and battery-operated equipment.
• Instrumentation and measurement devices.
• Telecommunications equipment.
• Distributed power architectures.

Features

• Input Voltage Range: 18-36 VDC (24V nominal)
• Output Voltage: 12 VDC
• Output Current: Up to 1.25 A
• Isolation Voltage: 1500 VDC
• Operating Temperature Range: -40°C to +85°C
• Efficiency: High efficiency
• Protection: Overload protection, short circuit protection
• Package: 2 x 1 inch

Benefits

• Wide Input Voltage Range: Allows for operation with varying DC input sources.
• Regulated Output Voltage: Provides a stable and reliable output voltage for sensitive electronic circuits.
• Input/Output Isolation: Protects the load from voltage transients and ground loops.
• Wide Operating Temperature Range: Suitable for use in harsh environments.
• High Efficiency: Minimizes power dissipation and improves system efficiency.
• Compact Size: Small package size saves valuable board space.

The TEN 15-2412 DC/DC converter is designed with advanced circuit topology to achieve high efficiency and reliable performance. The input filter minimizes reflected ripple current, ensuring compatibility with sensitive input sources. The output voltage is tightly regulated to maintain stability under varying load conditions. The converter is protected against overload and short circuit conditions to prevent damage. The isolation between the input and output provides electrical safety and prevents ground loops. The wide operating temperature range ensures reliable operation in a variety of environments. The compact 2 x 1 inch package size allows for easy integration into space-constrained applications. The converter is designed to meet industry safety standards. The high efficiency of the converter reduces heat dissipation and improves overall system efficiency. The rugged design ensures long-term reliability. The module is often used in applications requiring galvanic isolation between the power source and the load.
