9H03200030 TXC CORPORATION
Same model may have multiple batches, images only for reference.

9H03200030

Part No 9H03200030
Manufacturer TXC CORPORATION
Catalog Crystals
Description CRYSTAL 32.768KHZ 12.5PF SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer TXC CORPORATION
Packaging Reel
Type kHz Crystal (Tuning Fork)
Frequency 32.768kHz
Frequency Tolerance ±20ppm
Load Capacitance 12.5pF
ESR (Equivalent Series Resistance) 90 kOhms
Operating Mode Fundamental
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 2-SMD, No Lead
Dimension 0.063" L x 0.039" W (1.60mm x 1.00mm)
Height - Seated (Maximum) 0.020" (0.50mm)
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 803924-9H03200030
Ultra Librarian 3D Model Ultra Librarian 9H03200030 CAD Model

Description

The TXC CORPORATION 803924-9H03200030 is a kHz crystal (tuning fork).

  • Frequency: 32.768kHz
  • ESR (Equivalent Series Resistance): 90 kOhms
  • Frequency Tolerance: ±20ppm
  • Load Capacitance: 12.5pF
  • Mode: fundamental
  • Temperature Range: -40°C to 85°C
  • Package: 2-SMD, no lead
  • Height: 0.020" (0.50mm)
  • Popularity: popular
