The UM621024CM-70LL is a 1Mbit (128K x 8) low-power CMOS static RAM (SRAM) manufactured by UMC Corporation. This SRAM offers fast access times and low power consumption, making it suitable for various memory applications in embedded systems and portable devices.

Applications

• Embedded systems: Used as main or cache memory in embedded systems requiring fast access times and low power consumption.
• Data loggers: Employed in data loggers to store data temporarily before it is transferred to non-volatile memory.
• Industrial control systems: Utilized in industrial control systems for storing program code and data.
• Portable electronic devices: Found in portable devices such as handheld computers and PDAs for temporary data storage.
• Instrumentation: Used in test and measurement equipment for storing data acquired during measurements.

Features

• 1Mbit (128K x 8) memory: Provides 1Mbit of storage capacity organized as 128K words of 8 bits each.
• Fast access time: Offers fast access times, typically around 70ns, for quick data retrieval.
• Low power consumption: Consumes low power, making it suitable for battery-powered applications.
• CMOS technology: Utilizes CMOS technology for low power consumption and high noise immunity.
• TTL compatible inputs/outputs: Compatible with TTL logic levels for easy interfacing with other digital circuits.

Benefits

• Fast data access: Enables fast data access, improving system performance.
• Low power consumption: Minimizes power consumption, extending battery life in portable devices.
• Reliable data storage: Provides reliable data storage with high noise immunity.
• Easy integration: Easy to integrate into existing circuit designs due to TTL compatibility.
• Wide operating voltage range: Operates over a wide voltage range, providing flexibility in system design.

Additional Details

The UM621024CM-70LL typically operates from a 5V power supply. It has separate data input and output pins, allowing for easy connection to a microprocessor or microcontroller. Detailed timing diagrams, pin configurations, and electrical characteristics can be found in the official UMC datasheet. The component is usually available in a DIP (Dual In-line Package) or SOJ (Small Outline J-lead) package. Always refer to the official UMC datasheet for the most accurate and up-to-date specifications before using this component in a design.
