1N4249GP-E3/54

Part No 1N4249GP-E3/54
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 1KV 1A DO204AL
Datasheet
1N4249GP-E3/54 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1000V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.2V @ 1A
Speed(Frequency) Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 1μA @ 1000V
Capacitance @ Vr, F 8pF @ 4V, 1MHz
Mounting Through Hole
Case / Package DO-204AL (DO-41)
Operating Temperature - Junction -65°C to 160°C
Win Source Part Number 1002109-1N4249GP-E3/54
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 1N4249GP-E3/54 CAD Model

Description

The 1N4249GP-E3/54 is a standard diode manufactured by Vishay. It has a voltage rating of 1000 V and a current rating of 1 A. The diode is suitable for use in various applications, such as rectifiers, power supplies, and battery chargers. The supply and demand status is sufficient. The diode is capable of operating at a temperature range of -65°C to 160°C and has a standard recovery speed of >500ns, >200mA (Io).
