DG212BDY-T1-E3 Real Image DG212BDY-T1-E3 Vishay DG212BDY-T1-E3 Real Image DG212BDY-T1-E3 real image DG212BDY-T1-E3 real image3266
Same model may have multiple batches, images only for reference.
DG212BDY-T1-E3 Real Image DG212BDY-T1-E3 Vishay DG212BDY-T1-E3 Real Image DG212BDY-T1-E3 real image DG212BDY-T1-E3 real image3266
DG212BDY-T1-E3 Real Image DG212BDY-T1-E3 Vishay DG212BDY-T1-E3 Real Image DG212BDY-T1-E3 real image DG212BDY-T1-E3 real image3266
Same model may have multiple batches, images only for reference.

DG212BDY-T1-E3

Part No DG212BDY-T1-E3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description Analog Switch Quad SPST 16-Pin SOIC N T/R / IC SWITCH QUAD SPST 16SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Vishay
Packaging Reel - TR
Status Active
Switch Circuit SPST - NO
Number of Circuits 4
Max On Resistance 85 Ohm
Channel-to-Channel Matching (ΔRon) 2 Ohm
Single Supply Voltage (V+) 4.5 V to 25 V
Dual Supply Voltage(V±) ±4.5 V to 22 V
Max Switch Time (Ton,Toff) 300ns, 200ns
Charge Injection 1pC
Channel Capacitance(CS off, CD off) 5pF, 5pF
Max Leakage Current (IS off) 500pA
Crosstalk -95dB @ 100kHz
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-SOIC
Win Source Part Number 122825-DG212BDY-T1-E3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name DG212B
Introduction Date January 05, 1990
ECCN EAR99
Country of Origin China, Philippines, Taiwan, Thailand
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian DG212BDY-T1-E3 CAD Model

Description

DG212BDY-T1-E3 - Monolithic Analog Switch

The DG212BDY-T1-E3 is a robust monolithic switch that offers precision analog and digital signal switching. It ensures optimal performance in various applications.

Features and Benefits:

  • Low charge injection
  • Improved signal range with +/-15V analog voltage capability
  • High-temperature operation up to 85°C
  • Compact surface mount package

Applications:

  • Medical instrumentation
  • Data acquisition systems
  • Telecommunications
  • Industrial control systems

This model excels where reliability and high-speed operation are crucial.
