Same model may have multiple batches, images only for reference.

IRF640PBF

Name: IRF640PBF
Brand: Vishay
SKU: 159668
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF640PBF
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 200V 18A TO-220AB
Datasheet	IRF640PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Bulk
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	200V
Continuous Drain Current at 25°C	18A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	70nC @ 10V
Max Input Capacitance	1300pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	125W (Tc)
Maximum Rds On at Id,Vgs	180 mOhm @ 11A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	TO-220AB
Dimension	TO-220-3
Win Source Part Number	017454-IRF640PBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management
Family Name	IRF640
Introduction Date	March 27, 2007
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Ultra Librarian 3D Model	Ultra Librarian IRF640PBF CAD Model

Alternative Products

Description

The Vishay IRF640PBF is a N-Channel MOSFET that is widely used in power management applications.

Maximum Power Dissipation: 125W
Drain-Source Breakdown Voltage: 200V
Continuous Drain Current at 25°C: 18A (Tc)
Gate-Source Threshold Voltage: 4V @ 250μA
Maximum Rds On at Id, Vgs: 180 mOhm @ 11A, 10V
Maximum Gate-Source Voltage: ±20V
Maximum Gate Charge: 70nC @ 10V
Package: TO-220AB
Dimension: TO-220-3
Halogen-Free: Compliant
Manufactured in: China
Estimated EOL Date: 2024
