IRLL110TRPBF Real Image IRLL110TRPBF real image
Same model may have multiple batches, images only for reference.
IRLL110TRPBF Real Image IRLL110TRPBF real image
IRLL110TRPBF Real Image IRLL110TRPBF real image
Same model may have multiple batches, images only for reference.

IRLL110TRPBF

Part No IRLL110TRPBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 100V 1.5A 4-Pin(3+Tab) SOT-223 T/R / MOSFET N-CH 100V 1.5A SOT223
Datasheet
IRLL110TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 1.5A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4V, 5V
Gate-Source Threshold Voltage 2V @ 250μA
Max Gate Charge 6.1nC @ 5V
Max Input Capacitance 250pF @ 25V
Maximum Gate-Source Voltage ±10V
Power Dissipation (Max) 2W (Ta), 3.1W (Tc)
Maximum Rds On at Id,Vgs 540 mOhm @ 900mA, 5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223
Dimension TO-261-4, TO-261AA
Win Source Part Number 017758-IRLL110TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial, Power Management
Family Name IRLL110
Introduction Date March 27, 2007
ECCN EAR99
Country of Origin China, Israel, Taiwan
Halogen Free Not Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRLL110TRPBF CAD Model

Description

The Vishay IRLL110TRPBF is a high popularity electronic component that is manufactured by Vishay.

  • Polarity: N-Channel
  • Power Dissipation: 2W (Ta), 3.1W (Tc)
  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: 1.5A (Tc) @ 25°C
  • Gate-Source Threshold Voltage: 2V @ 250μA
  • Maximum Gate-Source Voltage: ±10V
  • Maximum Rds On: 540 mOhm @ 900mA, 5V
