SI2301BDS-T1-E3

Name: SI2301BDS-T1-E3
Brand: Vishay
SKU: 320955
Availability: InStock
Rating: 4.93 (141 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI2301BDS-T1-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET P-CH Si 20V 2.2A 3-Pin SOT-23 T/R / MOSFET P-CH 20V 2.2A SOT23-3
Datasheet	SI2301BDS-T1-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	2.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	2.5V, 4.5V
Gate-Source Threshold Voltage	950mV @ 250μA
Max Gate Charge	10nC @ 4.5V
Max Input Capacitance	375pF @ 6V
Maximum Gate-Source Voltage	±8V
Power Dissipation (Max)	700mW (Ta)
Maximum Rds On at Id,Vgs	100 mOhm @ 2.8A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3 (TO-236)
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	028359-SI2301BDS-T1-E3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Industrial, Power Management
Family Name	Si2301BDS
Introduction Date	November 08, 2002
ECCN	EAR99
Country of Origin	China
Halogen Free	Not Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian SI2301BDS-T1-E3 CAD Model

Alternative Products

Description

This SI2300DS MOSFET is a P-Channel polarity and manufactured by Vishay.

Power Dissipation (Max): 700mW (Ta)
Drain-Source Breakdown Voltage: 20V
Continuous Drain Current @ 25°C: 2.2A (Ta)
Maximum Rds On @ Id,Vgs: 100 mOhm @ 2.8A, 4.5V
Mounting: SMD (SMT)
Dimension: TO-236-3, SC-59, SOT-23-3
EOL Date (Estimated): 2022
