SI2302CDS-T1-GE3

Name: SI2302CDS-T1-GE3
Brand: Vishay
SKU: 320969
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI2302CDS-T1-GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 20V 2.6A SOT23-3
Datasheet	SI2302CDS-T1-GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	2.6A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	2.5V, 4.5V
Gate-Source Threshold Voltage	850mV @ 250μA
Max Gate Charge	5.5nC @ 4.5V
Maximum Gate-Source Voltage	±8V
Power Dissipation (Max)	710mW (Ta)
Maximum Rds On at Id,Vgs	57 mOhm @ 3.6A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3 (TO-236)
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	028363-SI2302CDS-T1-GE3
Family Name	Si2302CDS
Introduction Date	July 29, 2008
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial, Power Management, Portable Devices
Ultra Librarian 3D Model	Ultra Librarian SI2302CDS-T1-GE3 CAD Model

Alternative Products

Description

The Si2302CDS-T1-GE3 is an N-Channel MOSFET transistor that is suitable for use in a wide range of applications manufactured by Vishay.

Power Dissipation: 710mW @ -55°C to 150°C
Drain-Source Breakdown Voltage: 20V
Continuous Drain Current: 2.6A @ 25°C
Gate-Source Threshold Voltage: 850mV @ 250μA
Maximum Gate Charge: 5.5nC @ 4.5V
Package: SOT-23-3 (TO-236)
