SI2323DS-T1-E3

Name: SI2323DS-T1-E3
Brand: Vishay
SKU: 321057
Availability: InStock
Rating: 4.93 (108 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI2323DS-T1-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 20V 3.7A SOT23-3 / Trans MOSFET P-CH 20V 3.7A 3-Pin SOT-23 T/R
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	3.7A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	1.8V, 4.5V
Gate-Source Threshold Voltage	1V @ 250μA
Max Gate Charge	19nC @ 4.5V
Max Input Capacitance	1020pF @ 10V
Maximum Gate-Source Voltage	±8V
Power Dissipation (Max)	750mW (Ta)
Maximum Rds On at Id,Vgs	39 mOhm @ 4.7A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3 (TO-236)
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	028388-SI2323DS-T1-E3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Industrial
Family Name	Si2323DS
Introduction Date	October 03, 2002
ECCN	EAR99
Country of Origin	China, Taiwan
Halogen Free	Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian SI2323DS-T1-E3 CAD Model

Alternative Products

Description

The SI2323DS-T1-E3 MOSFET is an electronic component manufactured by Vishay.

Mounting Type: SMD (SMT)
Channel Type: P-channel
Category: discrete semiconductor products
Popularity: High
Application: Various electronic applications
Maximum Power Dissipation: 750mW (Ta)
Continuous Drain Current: 3.7A (Ta)
Drain-Source Breakdown Voltage: 20V
Gate-Source Threshold Voltage: 1V @ 250μA
Maximum Gate Charge: 19nC @ 4.5V
Maximum Input Capacitance: 1020pF @ 10V
