SI6981DQ-T1-GE3 Real Image SI6981DQ-T1-GE3 real image
Same model may have multiple batches, images only for reference.
SI6981DQ-T1-GE3 Real Image SI6981DQ-T1-GE3 real image
SI6981DQ-T1-GE3 Real Image SI6981DQ-T1-GE3 real image
Same model may have multiple batches, images only for reference.

SI6981DQ-T1-GE3

Part No SI6981DQ-T1-GE3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH 20V 4.1A 8-Pin TSSOP T/R / MOSFET 2P-CH 20V 4.1A 8-TSSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
FET Type 2 P-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 4.1A
Maximum Rds On at Id,Vgs 31 mOhm @ 4.8A, 4.5V
Gate-Source Threshold Voltage 900mV @ 300μA
Max Gate Charge 25nC @ 4.5V
Maximum Power Dissipation 830mW
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-TSSOP
Win Source Part Number 1096123-SI6981DQ-T1-GE3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Power Management
Family Name Si6981DQ
Introduction Date May 22, 2003
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian SI6981DQ-T1-GE3 CAD Model

Description

The Vishay Si6981DQ is a P-Channel Dual FET designed for power management applications. Vishay Si6981DQ

  • Channel Type: P-Channel
  • Design: Dual FET
  • Application: power management applications
  • Gate Type: logic level gate
  • Breakdown Voltage: 20V
  • Continuous Drain Current @ 25°C: 4.1A
  • Maximum Power Dissipation: 830mW
  • Gate-Source Threshold Voltage: 900mV @ 300μA
  • Maximum Gate Charge @ 4.5V: 25nC
  • Maximum Rds On @ Id,Vgs: 31 mOhm @ 4.8A and 4.5V
  • Package: 8-TSSOP
  • Operating Temperature Range: -55°C to 150°C
  • Product Status: obsolete and has reached its end of life
  • Halogen-Free: compliant with halogen-free regulations
  • Application: industrial power management applications
