SI7848BDP-T1-E3 Real Image SI7848BDP-T1-E3 Real Image
Same model may have multiple batches, images only for reference.
SI7848BDP-T1-E3 Real Image SI7848BDP-T1-E3 Real Image
SI7848BDP-T1-E3 Real Image SI7848BDP-T1-E3 Real Image
Same model may have multiple batches, images only for reference.

SI7848BDP-T1-E3

Part No SI7848BDP-T1-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 47A PPAK SO-8
Datasheet
SI7848BDP-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 47A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 50nC @ 10V
Max Input Capacitance 2000pF @ 20V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 4.2W (Ta), 36W (Tc)
Maximum Rds On at Id,Vgs 9 mOhm @ 16A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PowerPAK SO-8
Dimension PowerPAK SO-8
Win Source Part Number 028671-SI7848BDP-T1-E3
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian SI7848BDP-T1-E3 CAD Model

Description

The Vishay 028671-SI7848BDP-T1-E3 is a Discrete Semiconductor Product that belongs to the MOSFET technology.

  • Polarity: N-Channel
  • Maximum Power Dissipation: 4.2W (Ta), 36W (Tc)
  • Applications: power management, industrial, etc.
  • Supply and Demand Status: balanced
  • Maximum Drain-Source Breakdown Voltage: 40V
  • Continuous Drain Current: 47A (Tc)
  • Maximum Gate Charge: 50nC @ 10V
  • Maximum Input Capacitance: 2000pF @ 20V
  • Package: 3k pcs
