SIHG20N50C-E3

Name: SIHG20N50C-E3
Brand: Vishay
SKU: 323470
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	SIHG20N50C-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 500V 20A TO247
Datasheet	SIHG20N50C-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Bulk
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	500V
Continuous Drain Current at 25°C	20A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	5V @ 250μA
Max Gate Charge	76nC @ 10V
Max Input Capacitance	2942pF @ 25V
Maximum Gate-Source Voltage	±30V
Power Dissipation (Max)	250W (Tc)
Maximum Rds On at Id,Vgs	270 mOhm @ 10A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	TO-247AC
Dimension	TO-247-3
Win Source Part Number	090888-SIHG20N50C-E3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	SiHG20N50C
Introduction Date	June 28, 2009
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Ultra Librarian 3D Model	Ultra Librarian SIHG20N50C-E3 CAD Model

Alternative Products

Description

The 090888-SIHG20N50C-E3 MOSFET is an N-channel device with a drain-source breakdown voltage of 500V and a continuous drain current of 20A at 25°C.

Drain-Source Breakdown Voltage: 500V
Continuous Drain Current: 20A @ 25°C
Gate-Source Threshold Voltage: 5V @ 250μA
Maximum Gate Charge: 76nC @ 10V
Maximum Rds On: 270 mOhm @ 10A, 10V
Package: TO-247AC
Maximum Input Capacitance: 2942pF @ 25V
Power Dissipation (Tc): 250W
Operating Temperature Range (TJ): -55°C to 150°C
