Same model may have multiple batches, images only for reference.

SQ7415AEN-T1_GE3

Name: SQ7415AEN-T1_GE3
Brand: Vishay
SKU: 518509
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

Part No	SQ7415AEN-T1_GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 60V 16A 1212-8
Datasheet	SQ7415AEN-T1_GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	60V
Continuous Drain Current at 25°C	16A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.5V @ 250μA
Max Gate Charge	38nC @ 10V
Max Input Capacitance	1385pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	53W (Tc)
Maximum Rds On at Id,Vgs	65 mOhm @ 5.7A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	PowerPAK 1212-8
Dimension	PowerPAK 1212-8
Win Source Part Number	1101716-SQ7415AEN-T1_GE3
Family Name	SQ7415AEN
ECCN	EAR99
Halogen Free	Compliant
Estimated EOL Date	2026
Ultra Librarian 3D Model	Ultra Librarian SQ7415AEN-T1_GE3 CAD Model

Alternative Products

Description

The Vishay 1101716-SQ7415AEN-T1_GE3 is a P-channel MOSFET designed for discrete semiconductor products.

Channel Type: P-Channel
Power Dissipation: 53W
Continuous Drain Current: 16A @ 25°C
Gate-Source Threshold Voltage: 2.5V @ 250μA
Gate Charge: 38nC @ 10V
Input Capacitance: 1385pF @ 25V
Gate-Source Voltage: ±20V
Package: PowerPAK 1212-8
Drain-Source Breakdown Voltage: 60V
Status: Active
Estimated EOL Date: 2026
Halogen-Free: Yes
Alternative Parts: DMP6050SFG-7, DMP6050SFG-13, NVTFS5116PLTWG
