SQD19P06-60L_GE3 Real Image SQD19P06-60L_GE3 real image11184 SQD19P06-60L_GE3 Real Image
Same model may have multiple batches, images only for reference.
SQD19P06-60L_GE3 Real Image SQD19P06-60L_GE3 real image11184 SQD19P06-60L_GE3 Real Image
SQD19P06-60L_GE3 Real Image SQD19P06-60L_GE3 real image11184 SQD19P06-60L_GE3 Real Image
Same model may have multiple batches, images only for reference.

SQD19P06-60L_GE3

Part No SQD19P06-60L_GE3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 60V 20A TO252
Datasheet
SQD19P06-60L_GE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 20A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 250μA
Max Gate Charge 41nC @ 10V
Max Input Capacitance 1490pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 46W (Tc)
Maximum Rds On at Id,Vgs 55 mOhm @ 19A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1101721-SQD19P06-60L_GE3
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SQD19P06-60L_GE3 CAD Model

Description

Vishay presents an electronic component with the Win Source Part Number 1101721-SQD19P06-60L_GE3.

  • Category: Discrete Semiconductor Products
  • Status: active
  • Mounting Type: SMD (SMT)
  • Polarity: P-Channel MOSFET
  • Power Dissipation: 46W (Tc)
  • Drain-Source Breakdown Voltage: 60V
  • Continuous Drain Current: 20A (Tc)
  • Gate Charge: 41nC @ 10V
