SS2PH10HM3/85A Vishay SS2PH10HM3/85A Real Image SS2PH10HM3/85A real image 2 SS2PH10HM3/85A label picture
Same model may have multiple batches, images only for reference.
SS2PH10HM3/85A Vishay SS2PH10HM3/85A Real Image SS2PH10HM3/85A real image 2 SS2PH10HM3/85A label picture
SS2PH10HM3/85A Vishay SS2PH10HM3/85A Real Image SS2PH10HM3/85A real image 2 SS2PH10HM3/85A label picture
Same model may have multiple batches, images only for reference.

SS2PH10HM3/85A

Part No SS2PH10HM3/85A
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description Rectifier Diode Schottky 100V 2A Automotive 2-Pin SMP T/R / DIODE SCHOTTKY 100V 2A DO220AA
Datasheet
SS2PH10HM3/85A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 800mV @ 2A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1μA @ 100V
Capacitance @ Vr, F 65pF @ 4V, 1MHz
Mounting SMD (SMT)
Case / Package DO-220AA (SMP)
Operating Temperature - Junction -55°C to 175°C
Win Source Part Number 1102129-SS2PH10HM3/85A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management, Safety
Family Name SS2PH10
Introduction Date November 09, 2006
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian SS2PH10HM3/85A CAD Model

Description

The Vishay is a high-quality electronic component.

  • Win Source Part Number: 1102129-SS2PH10HM3/85A
  • Manufacturer: Vishay
  • Packaging: Reel - TR
  • Mounting: SMD (SMT)
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 100V
  • Current - Average Rectified (Io): 2A
  • Voltage - Forward (Vf) (Max) @ If: 800mV @ 2A
  • Current - Reverse Leakage @ Vr: 1μA @ 100V
  • Capacitance @ Vr, F: 65pF @ 4V, 1MHz
  • Operating Temperature - Junction: -55°C to 175°C
  • Family Name: SS2PH10
  • Categories: Discrete Semiconductor Products
  • Status: Obsolete(EOL)
  • Case / Package: DO-220AA (SMP)
  • Speed(Frequency): Fast Recovery = 200mA (Io)
  • Alternative Parts (Cross-Reference): SS2PH10HM3_A/H, SS2PH10HM3_A/I, CD1206-B2100, and SS2PH10HE3/85A
  • Introduction Date: November 09, 2006
  • ECCN: EAR99
  • Estimated EOL Date: Obsolete / End of life
  • Halogen Free: Compliant
  • Supply and Demand Status: Limited
  • Applications: Power Management, Safety
