SUD25N15-52-E3 Real Image SUD25N15-52-E3 Real Image
Same model may have multiple batches, images only for reference.
SUD25N15-52-E3 Real Image SUD25N15-52-E3 Real Image
SUD25N15-52-E3 Real Image SUD25N15-52-E3 Real Image
Same model may have multiple batches, images only for reference.

SUD25N15-52-E3

Part No SUD25N15-52-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 150V 25A TO252 / Trans MOSFET N-CH 150V 25A 3-Pin(2+Tab) DPAK
Datasheet
SUD25N15-52-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 150V
Continuous Drain Current at 25°C 25A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 40nC @ 10V
Max Input Capacitance 1725pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3W (Ta), 136W (Tc)
Maximum Rds On at Id,Vgs 52 mOhm @ 5A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 031609-SUD25N15-52-E3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name SUD25N15-52
Introduction Date January 02, 2002
ECCN EAR99
Country of Origin China, Taiwan
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SUD25N15-52-E3 CAD Model

Description

This Vishay MOSFET is a surface mountable electronic component that belongs to the category of discrete semiconductor products.

  • Manufacturer: Vishay
  • Product Name: SUD25N15-52-E3
  • Win Source Part Number: 031609
  • Family: SUD25N15-52 series
  • Mounting Type: Surface Mount
  • Power Rating: 3 watts (Ta)
  • Breakdown Voltage: 150V
