The SUP75N06-08-E3 is an N-Channel power MOSFET from Vishay, engineered for high-efficiency switching in a broad spectrum of applications. This MOSFET features a low on-resistance and fast switching speeds, making it ideal for use in DC-DC converters, power supplies, and motor control circuits. The “E3” suffix indicates compliance with RoHS standards, making it environmentally friendly.

Applications:

• DC-DC Converters: Efficient power conversion in a variety of electronic devices.
• Power Supplies: Regulation and switching in power supply units.
• Motor Control: Precise and efficient control of electric motors.
• Load Switching: Efficient switching of power to various loads.
• Automotive Applications: Use in various automotive electronic systems.

Features:

• N-Channel MOSFET: Offers fast and efficient switching capabilities.
• Low On-Resistance (RDS(on)): Minimizes conduction losses, improving efficiency.
• Fast Switching Speed: Reduces switching losses and allows for higher frequency operation.
• High Current Capability: Supports high current loads.
• Avalanche Rated: Provides robustness against voltage transients.
• TrenchFET® Power MOSFET Technology: Enables high power density and efficiency.
• Lead (Pb)-free and RoHS Compliant (E3 Suffix): Meets environmental regulations.

Benefits:

• Increased Efficiency: Low RDS(on) reduces power dissipation, leading to higher system efficiency.
• Reduced Switching Losses: Fast switching speed minimizes energy loss during switching transitions.
• Improved Reliability: Avalanche rating ensures robustness in demanding conditions.
• Simplified Design: Can be driven by standard gate drive circuits.
• Environmentally Friendly: RoHS compliant, reducing environmental impact.

Additional Details:

The SUP75N06-08-E3 features a drain-source voltage (VDS) rating of 60V and a continuous drain current (ID) rating of 75A, depending on the operating temperature and package thermal resistance. The on-resistance (RDS(on)) is very low, minimizing power dissipation during conduction. It is typically packaged in a TO-220 or similar package for efficient heat dissipation. The gate threshold voltage is designed for compatibility with standard gate drive circuits. This MOSFET is well-suited for high-efficiency power conversion applications where low losses and robust performance are critical. The fast switching speed contributes to reduced switching losses and improved overall efficiency.
