VOL618A-3X001T

Name: VOL618A-3X001T
Brand: Vishay
SKU: 803716
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	VOL618A-3X001T
Manufacturer	Vishay
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISOLATOR 5KV TRANS 4-LSOP / Optocoupler, Phototransistor Output, Low Input Current, 4 Pin LSOP, Long Creepage Mini-Flat Package
Datasheet	VOL618A-3X001T Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Vishay Semiconductor Opto Division
Packaging	Reel
Number of Channels	1
Voltage - Isolation	5000Vrms
Current Transfer Ratio (Min)	100% at 1mA
Current Transfer Ratio (Maximum)	200% at 1mA
Turn On / Turn Off Time (Typ)	6μs, 5.5μs
Rise / Fall Time (Typ)	3.5μs, 5μs
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	80V
Current - Output / Channel	50mA
Voltage - Forward (Vf) (Typ)	1.16V
Current - DC Forward (If) (Maximum)	60mA
Vce Saturation (Maximum)	400mV
Temperature Range - Operating	-55°C ~ 110°C
Mounting Style	SMD
Manufacturer Package	4-SMD, Gull Wing
Supplier Device Package	4-LSOP (2.54mm)
Manufacturer Pack Quantity	3,000
MSL Level	1 (Unlimited)
Popularity	Medium
Supply and Demand Status	Balance
Win Source Part Number	803716-VOL618A-3X001T
Ultra Librarian 3D Model	Ultra Librarian VOL618A-3X001T CAD Model

Alternative Products

Description

The Vishay Semiconductor Opto Division 803716-VOL618A-3X001T is a transistor output optocoupler.

Applications: Industrial Control Systems, Automotive Systems, Consumer Electronics
Isolation Voltage: High
Response Time: Fast
Current Transfer Ratio: High
RoHS Compliant: Yes
Popularity: Medium
Supply and Demand Status: Balanced
