The CC0603JRX7R9BB332 is a ceramic capacitor manufactured by Yageo. This capacitor is designed for general-purpose applications where a stable and reliable capacitance is required. It belongs to the X7R dielectric family, which signifies its performance characteristics over temperature variations. This makes it suitable for use in various electronic circuits, including filtering, decoupling, and bypass applications.

Applications

• Bypass Capacitors
• Decoupling Capacitors
• Filtering Circuits
• Timing Circuits
• General Electronic Circuits

Features

• Capacitance: 3.3pF
• Voltage Rating: 50V
• Tolerance: ±0.1pF
• Dielectric: X7R
• Case Size: 0603 (1608 Metric)
• Termination Style: SMD/SMT (Surface Mount)

Benefits

• Stable Performance: X7R dielectric provides stable capacitance over a wide temperature range (-55°C to +125°C).
• Compact Size: The 0603 case size allows for high-density mounting on PCBs, saving space.
• Reliable: Ceramic capacitors offer high reliability and long lifespan.
• Cost-Effective: Suitable for high-volume production due to its low cost.
• RoHS Compliant: Meets environmental standards, making it suitable for global distribution.

Additional Details

The X7R dielectric ensures that the capacitance changes by no more than ±15% over its operating temperature range. The 0603 package provides a balance between size and ease of handling during the assembly process. Surface mount technology (SMT) allows for automated placement and soldering, reducing manufacturing costs and increasing production efficiency. The capacitor is non-polarized, simplifying circuit design and installation. The CC0603JRX7R9BB332 is suitable for applications where precise capacitance values and stability are important design considerations. Its small size and robust construction make it a versatile component for modern electronic devices.
