Same model may have multiple batches, images only for reference.

BC857BS

Name: BC857BS
Brand: Yangzhou yangjie electronic co., ltd
SKU: 569454
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	BC857BS
Manufacturer	Yangzhou yangjie electronic co., ltd
Catalog	Transistors (BJT) - Arrays
Description	SOT-363 PNP+PNP 0.3W -0.1A -50V / Bipolar (BJT) Transistor Array 45V 200mA 300mW Surface Mount SOT-363
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Bipolar Transistor Arrays
Mfr	Yangzhou yangjie electronic co., ltd
Package	Tape & Reel
Product Status	Active
Current - Collector (Ic) (Max)	200mA
Voltage - Collector Emitter Breakdown (Max)	45V
Vce Saturation (Max) @ Ib, Ic	650mV @ 5mA, 100mA
Current - Collector Cutoff (Max)	15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	220 @ 2mA, 5V
Power - Max	300mW
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	6-TSSOP, SC-88, SOT-363
Supplier Device Package	SOT-363
Base Product Number	BC857
Standard Package	3,000 pcs
REACH Status	REACH Unaffected
ECCN	EAR99
Win Source Part Number	569454-BC857BS
Ultra Librarian 3D Model	Ultra Librarian BC857BS CAD Model

Alternative Products

Description

The 569454-BC857BS is a bipolar transistor array designed for surface mount applications manufactured by Yangzhou yangjie electronic co., ltd.

Maximum Power: 300mW
Maximum Collector-Emitter Breakdown Voltage: 45V
Maximum Collector Current: 200mA
Vce Saturation: 650mV @ maximum base current and collector current
Package: Tape and Reel
Standard Package: 3,000 pieces
Operating Temperature: -55°C to 150°C
Product Status: Active
REACH Compliance: Not affected by REACH regulations
