The S-1135D13-A6T1U is a positive voltage regulator IC from ABLIC U.S.A. Inc., part of the S-1135 series known for its low current consumption and high precision. This regulator provides a stable output voltage, irrespective of variations in the input voltage or the load current.

Applications

• Power management in handheld gaming devices
• Voltage regulation for portable barcode scanners
• Battery-operated point-of-sale (POS) terminals
• Power supply for low-power RF modules
• Regulation in security systems

Features

• Output Voltage: 1.3V
• Input Voltage Range: 2.0V to 5.5V
• Output Voltage Accuracy: ±1.0%
• Low Current Consumption: 9.0μA (typical)
• Package: SOT-25A
• Overcurrent Protection: Safeguards against excessive output current.
• Thermal Shutdown: Prevents overheating and potential damage to the IC.
• Low Dropout Voltage: Enables efficient regulation even with minimal input-output voltage differential.

Benefits

• Consistent Voltage Output: Ensures stable and reliable operation of connected electronic devices.
• Extended Battery Life: Minimizes power consumption, maximizing the operating time of battery-powered devices.
• Precise Voltage Control: Accurate voltage regulation is crucial for sensitive electronic components.
• Compact Size: Small SOT-25A package allows for use in space-constrained applications.
• Reliable Performance: Built-in protection features guarantee robust and dependable operation.
• Simplified Circuit Design: Reduces the requirement for external components, simplifying the design process.

The S-1135D13-A6T1U voltage regulator is ideally suited for applications requiring a stable, precise, and efficient voltage supply in a compact form factor. Its integrated protection features and low current consumption make it a prime choice for various portable and battery-powered devices, contributing to enhanced performance and prolonged lifespan.
