AO4805 Alpha & Omega Semiconductor Inc. AO4805 Real Image AO4805 label picture
Same model may have multiple batches, images only for reference.
AO4805 Alpha & Omega Semiconductor Inc. AO4805 Real Image AO4805 label picture
AO4805 Alpha & Omega Semiconductor Inc. AO4805 Real Image AO4805 label picture
Same model may have multiple batches, images only for reference.

AO4805

Part No AO4805
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2P-CH 30V 9A 8-SOIC
Datasheet
AO4805 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
FET Type 2 P-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 9A
Maximum Rds On at Id,Vgs 19 mOhm @ 8A, 10V
Gate-Source Threshold Voltage 2.8V @ 250μA
Max Gate Charge 39nC @ 10V
Max Input Capacitance 2600pF @ 15V
Maximum Power Dissipation 2W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 009762-AO4805
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AO4805 CAD Model

Description

AO4805 MOSFET

The AO4805 is a versatile dual N-channel MOSFET ideal for high-speed switching applications. Its high durability and low power consumption make it suitable for a wide range of industrial and commercial electronic applications.

Features and Benefits

  • High-speed switching capabilities
  • Durable, high-quality construction
  • Low power consumption

Applications

  • High-speed signal processing
  • Power conversion systems
  • Industrial control systems
