The BERGSTIK™ header connector is a 20-position male pin connector, with a pitch of 0.100” (2.54mm) and a row spacing of 0.100” (2.54mm).

• Connector Type: Header
• Number of Positions: 20
• Pitch: 0.100” (2.54mm)
• Row Spacing: 0.100” (2.54mm)
• Connection Type: Board-to-Board
• Fastening Type: Push-Pull
• Insulation Material: Thermoplastic
• Contact Material: Phosphor Bronze
• Contact Finish Mating: Gold, GXT™, 15.0µin (0.38µm)
• Contact Finish Post: Tin, 78.7µin (2.00µm)
• Operating Temperature: -65°C to 125°C
• Packaging: Tape and Reel
• Standard Package: 300
