AD5686RBRUZ NanoDAC+™ by Analog Devices Inc.

The AD5686RBRUZ, part of the NanoDAC+™ series from Analog Devices Inc., is a robust and high-precision digital-to-analog converter (DAC) designed to cater to a wide array of applications requiring digital control over analog outputs. This quad-channel, 16-bit DAC offers an impressive integration of features in a compact TSSOP package, making it an ideal choice for space-constrained applications.

Key Features

• Resolution: The device boasts a 16-bit resolution, providing fine granularity and high precision in analog output.
• Quad Channels: It features four DAC channels that can be individually programmed, offering flexibility for multiple output configurations.
• Output Range: The AD5686RBRUZ supports a selectable output range, including 0 V to 5 V, 0 V to 10 V, ±5 V, and ±10 V, accommodating a variety of use cases.
• On-Chip Reference: An integrated 2.5 V, 2 ppm/°C reference voltage source simplifies design and enhances stability.
• Interface: Communication with the device is achieved through a serial peripheral interface (SPI), which is compatible with QSPI™, MICROWIRE™, and DSP interface standards.
• Power Supply: The DAC operates from a single 2.7 V to 5.5 V supply, providing design flexibility in various power environments.
• Power-Down Function: It includes a power-down function that reduces the current consumption to 4 µA at 5 V, contributing to power efficiency in the system.
• Package: Housed in a compact 16-lead TSSOP package, the AD5686RBRUZ saves valuable board space without compromising performance.

Applications

The AD5686RBRUZ is suitable for a diverse range of applications, including:

• Process control and automation systems
• Data acquisition systems
• Digital gain and offset adjustment
• Programmable voltage and current sources
• Portable battery-powered instruments
• Waveform generation

With its combination of high precision, compact footprint, and multiple output ranges, the AD5686RBRUZ from Analog Devices Inc. stands as a versatile and dependable solution for any system requiring high-quality digital-to-analog conversion.
