AD603AR-REEL

Part No AD603AR-REEL
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP VGA 90MHZ 8SOIC
Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Amplifier Type Variable Gain
Number of Circuits 1
Slew Rate 275 V/μs
-3db Bandwidth 90MHz
Current - Input Bias 200nA
Operating Supply Current 12.5mA
Channel Output Current 50mA
Supply Voltage - Operating 9.5 V to 12.6 V, ±4.75 V to 6.3 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 115764-AD603AR-REEL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD603AR-REEL CAD Model

Description

Product Overview: AD603AR-REEL by Analog Devices Inc.

The AD603AR-REEL is a versatile, low noise, voltage-controlled amplifier designed for a wide array of applications including medical instrumentation, professional audio, and communication systems. Manufactured by Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing integrated circuits, this product offers precision performance in a compact package.

Key Features:

  • Variable Gain: The AD603AR-REEL provides a gain range of 0 dB to 90 dB, controlled by a single positive voltage, offering exceptional flexibility for dynamic range processing.
  • Low Noise: With an emphasis on clean signal amplification, it boasts an extremely low noise figure, making it ideal for sensitive audio and instrumentation applications.
  • High Bandwidth: This amplifier operates with a bandwidth of 90 MHz at a gain of +20 dB, ensuring that signals are processed with minimal distortion and high fidelity.
  • Dual-Mode Operation: It can be configured in either a linear-in-dB mode or a linear-in-volts mode, depending on the application requirements, providing designers with a high degree of versatility.
  • Single Supply Operation: The AD603AR-REEL can operate from a single supply voltage, simplifying power supply design and reducing system power requirements.

Applications:

  • IF/RF AGC Amplifiers
  • Ultrasound Gain Control
  • Audio/Video Faders and Level Controls
  • ADC Preamp Gain Control
  • Automated Test Equipment (ATE)

The AD603AR-REEL is available in a robust surface-mount package, making it suitable for automated manufacturing processes. Its reliability and performance are assured by Analog Devices' rigorous testing and quality control processes. Whether for high-precision medical equipment or for professional-grade audio systems, the AD603AR-REEL offers a combination of features that can enhance performance and simplify design.

For designers and engineers looking for a high-performance, adjustable gain amplifier, the AD603AR-REEL from Analog Devices Inc. represents a top-tier solution that balances functionality, reliability, and ease of use.
