AD815ARBZ-24

Part No AD815ARBZ-24
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC AMP DIFF DUAL LDIST 24SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tube/Rail
Status Active
Amplifier Type Differential
Number of Circuits 2
Slew Rate 900 V/μs
-3db Bandwidth 120MHz
Current - Input Bias 10μA
Voltage - Input Offset 10mV
Operating Supply Current 30mA
Channel Output Current 500mA
Supply Voltage - Operating 10 V to 36 V, ±5 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 24-SOIC w/Batwing
Win Source Part Number 107512-AD815ARBZ-24
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD815ARBZ-24 CAD Model

Description

Product Overview: AD815ARBZ-24

The AD815ARBZ-24 is a high-performance audio amplifier designed and manufactured by Analog Devices Inc., a leader in precision high-performance integrated circuits. This component is engineered to deliver superior sound quality and reliability for a wide range of audio applications.

Key Features

  • High Output Current: The AD815ARBZ-24 is capable of delivering a significant amount of current, making it suitable for driving a variety of loads, including low-impedance headphones or speakers.
  • Wide Bandwidth: With an impressive bandwidth, this audio amplifier can handle a broad spectrum of frequencies, ensuring high-fidelity audio reproduction for both musical content and voice signals.
  • Low Distortion: The device is designed to minimize total harmonic distortion (THD), which is crucial for maintaining the clarity and quality of the audio signal.
  • Flexible Power Supply: It operates over a wide range of power supply voltages, accommodating various system requirements.
  • Thermal Protection: The AD815ARBZ-24 incorporates thermal protection circuitry, which prevents damage from overheating, enhancing the longevity and reliability of the product.

Applications

  • High-quality audio amplification
  • Professional audio equipment
  • Studio and broadcast audio systems
  • Home theater and entertainment systems
  • Active speakers and subwoofers

Product Specifications

The AD815ARBZ-24 comes in a robust package designed for optimal thermal and electrical performance. It features dual amplifiers with high output drive capability, and it is optimized for low noise and distortion, making it an ideal choice for demanding audio applications. The device also includes advanced protection features to ensure safe operation under a variety of conditions.

Quality and Support

Analog Devices Inc. is known for its commitment to quality, and the AD815ARBZ-24 is no exception. Customers can expect comprehensive technical support and resources, including datasheets, reference designs, and application notes to facilitate the integration of this audio amplifier into their projects.

Whether you're designing a high-end audio system or looking for a reliable solution for commercial audio applications, the AD815ARBZ-24 from Analog Devices Inc. offers the performance, quality, and support you need to deliver outstanding audio experiences.
