AD8429ARZ-R7

Part No AD8429ARZ-R7
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC INST AMP 1 CIRCUIT 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 12 Weeks
Features Instrumentation Amplifier Circuit - 8-SOIC
Manufacturer Analog Devices Inc.
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C
Mounting Surface Mount
Package 8-SOIC (0.154", 3.90mm Width)
Case / Package 8-SOIC
Family Name AD8429
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.33.0001
Other Part Number AD8429ARZ-R7DKR, AD8429ARZ-R7CT, AD8429ARZR7, AD8429ARZ-R7-ND, AD8429ARZ-R7TR
Quantity per package 1000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 909931-AD8429ARZ-R7
Ultra Librarian 3D Model Ultra Librarian AD8429ARZ-R7 CAD Model

Description

Overview of AD8429ARZ-R7 by Analog Devices Inc.

The AD8429ARZ-R7 is a high-performance, low-noise instrumentation amplifier designed by Analog Devices Inc., a leader in precision signal processing technology. This amplifier is well-suited for a range of applications that require exacting electrical measurements, including medical instrumentation, industrial process controls, and precision data acquisition systems.

Key Features

  • High Gain Accuracy: The AD8429 offers exceptional gain accuracy and linearity, which is essential for precision measurement applications.
  • Low Noise Performance: With its low noise density of 1 nV/√Hz at 1 kHz, the AD8429 ensures signal fidelity and minimizes the need for additional filtering.
  • Wide Bandwidth: A bandwidth of 10 MHz when configured at a gain of 1, allows the AD8429 to handle a broad range of signals without compromising speed.
  • High Common-Mode Rejection Ratio (CMRR): With a CMRR of 130 dB (minimum) at 60 Hz, the device is highly resistant to interference from unwanted common-mode signals.
  • Low Input Bias Current: The low input bias current of the AD8429 reduces errors in applications with high source impedance.
  • Flexible Power Supply: It operates with dual supplies ranging from ±4 V to ±18 V, or a single supply of 8 V to 36 V, providing versatility in various circuit configurations.

Applications

  • Medical instrumentation such as ECG and EEG monitors
  • Industrial process controls and monitoring systems
  • Precision data acquisition systems
  • Strain gauge and pressure sensor amplifiers
  • Thermocouple amplifiers

The AD8429ARZ-R7 comes in a compact SOIC package, which is conducive for space-constrained applications while also ensuring ease of integration into a wide array of circuit designs. Its robust design and high precision make it an ideal choice for engineers and designers looking to enhance the performance and accuracy of their measurement systems.

Analog Devices Inc. has built a reputation for providing high-quality, reliable components, and the AD8429ARZ-R7 is no exception. It represents a blend of precision, performance, and versatility, making it a top choice for anyone in need of a superior instrumentation amplifier.
