ADM811TARTZ-REEL - A Reliable Microprocessor Supervisor from Analog Devices Inc.

The ADM811TARTZ-REEL is a robust supervisory circuit from Analog Devices Inc., designed for monitoring power supply and microprocessor system functions. This device is particularly useful in managing system resets and ensuring that the microprocessor powers up and operates correctly. It comes in a compact package and is part of a series that is widely recognized for its reliability and efficiency in various applications.

Key Features:

• Power Supply Monitoring: The ADM811TARTZ-REEL keeps a vigilant eye on the system's power supply, ensuring that the voltage levels remain within acceptable thresholds for stable operation.
• Automatic Reset Generation: Upon detection of an out-of-tolerance power supply, the device automatically generates a reset signal to the microprocessor, which continues until the supply voltage returns to an acceptable level.
• Manual Reset Input: This feature allows for an external signal to trigger a system reset, providing additional control to the user or system operator.
• Low Power Consumption: With its design focused on efficiency, the ADM811TARTZ-REEL consumes minimal power, making it ideal for power-sensitive applications.
• Wide Operating Temperature Range: The device is designed to operate over a broad temperature range, ensuring reliability across various environmental conditions.

Applications:

The versatility of the ADM811TARTZ-REEL makes it suitable for a wide array of applications, including but not limited to:

• Portable/Battery-Powered Equipment
• Computers and Controllers
• Intelligent Instruments
• Automotive Systems

Technical Specifications:

• Package: SOT-143
• Output Type: Active Low, Open Drain
• Number of Voltages Monitored: Single
• Threshold Voltage: 4.63V
• Operating Temperature: -40°C to +125°C
• Mounting Type: Surface Mount
• Supply Voltage: 2.7V to 5.5V

In conclusion, the ADM811TARTZ-REEL from Analog Devices Inc. is a high-quality, reliable solution for system monitoring and reset management. Its integration into a system ensures improved stability, performance, and protection for critical components, making it a valuable asset in any microprocessor-based application.
