Product Overview: ADV7611WBSWZ

The ADV7611WBSWZ is a high-performance, low-power HDMI receiver integrated circuit (IC) designed and manufactured by Analog Devices Inc. This IC is capable of receiving HDMI signals up to 1080p or UXGA (1600x1200) at 60Hz. It is an ideal solution for applications that require the reliable reception of high-definition multimedia content.

Key Features

• High-Definition Multimedia Interface (HDMI) 1.4 Features: The ADV7611 supports 3D video formats, extended colorimetry including sYCC601, Adobe RGB, Adobe YCC601, and deep color up to 36 bits per pixel.
• Integrated Equalizer: Features an on-chip equalizer for cable lengths up to 30 meters, ensuring signal integrity over long cable runs.
• Audio Support: Capable of handling I2S and SPDIF audio outputs, supporting up to 8 channels of 192kHz audio or 2 channels of 768kHz audio.
• Low Power Consumption: Designed for power-sensitive applications, the ADV7611 has a low power consumption mode that significantly reduces power usage when in standby.
• Content Protection: HDCP 1.4 compliant, providing secure handling of high-definition content.
• Programmable: The device features a flexible programming interface that can be configured via I2C, allowing for customization and control over various functions.

Applications

The ADV7611WBSWZ is versatile and can be used in a wide range of applications, including:

• Audio/Video Receivers
• Blu-ray Players and Home Theater Systems
• Professional Video Cameras and Monitors
• Video Conferencing Systems
• Automotive Infotainment and Entertainment Systems
• Medical Imaging and Video Equipment

Package and Quality

The ADV7611WBSWZ is offered in a compact LQFP (Low Profile Quad Flat Package) that is designed for easy integration into various electronic systems. Analog Devices Inc. is known for its commitment to quality, and this product is no exception, meeting high industry standards for performance and reliability.

For design engineers and system integrators looking for a robust and feature-rich HDMI receiver, the ADV7611WBSWZ from Analog Devices Inc. offers the perfect blend of performance, power efficiency, and advanced functionalities.
