Product Overview: LT8302MPS8E#TRPBF from Analog Devices Inc.

The LT8302MPS8E#TRPBF is a high-performance, monolithic flyback regulator from Analog Devices Inc. that simplifies the design of an isolated DC/DC converter. With no optocoupler, third winding, or signal transformer required for feedback since the output voltage is sensed from the primary-side flyback waveform, this product offers a streamlined solution for power supply design.

This regulator operates over a 3V to 100V input voltage range, making it suitable for a wide array of applications, including industrial, automotive, and telecommunications power systems. The device is capable of producing an output power up to 6 watts with no heat sink, and even higher power outputs with appropriate thermal management, making it a versatile choice for various power conversion needs.

The LT8302MPS8E#TRPBF utilizes a low ripple Burst Mode operation to maintain high efficiency at low output currents, which is critical for energy-saving requirements in standby and no-load conditions. Additionally, its internal compensation minimizes external parts count, further simplifying the design process and reducing overall solution size.

Key features of the LT8302MPS8E#TRPBF include:

• Wide input voltage range: 3V to 100V
• Internal 2A, 150V switch
• No optocoupler required for regulation
• Low ripple Burst Mode operation for high efficiency at light loads
• Programmable soft-start function
• Thermal shutdown for over-temperature protection
• Available in a small thermally enhanced 8-lead MSOP package

For safety and reliability, the device features robust protection capabilities, including output short-circuit protection, open feedback loop protection, and a programmable input undervoltage lockout. These features ensure that the LT8302MPS8E#TRPBF can handle a variety of fault conditions without damage to the device or the system it powers.

Engineers looking for a compact, efficient, and easy-to-implement isolated power solution will find the LT8302MPS8E#TRPBF an excellent choice. With its combination of performance, integration, and safety features, this regulator streamlines the design of isolated DC/DC converters for a wide range of applications.
