DAC08AQ

Part No DAC08AQ
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - Digital to Analog Converters (DAC)
Description 8-Bit, High Speed, Multiplying D/A Converter (Universal Digital Logic Interface)
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Tube
Resolution 8
Number of D/A Converters 1
Settling Time 135μs
Output Type Current - Unbuffered
Differential Output Yes
Data Interface Parallel
Reference Type External
Operating Supply Voltage ±4.5 V ~ 18 V
Voltage - Supply, Digital 9 V ~ 36 V
Architecture Multiplying DAC
Operating Temperature Range -55°C ~ 125°C
Package 16-CDIP (0.300", 7.62mm)
Manufacturer Package 16-CDIP
Win Source Part Number 1166358-DAC08AQ
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Limited
Family Name DAC08
Introduction Date September 11, 1996
ECCN 3A001.a.2.c
Country of Origin Philippines
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian DAC08AQ CAD Model

Description

Analog Devices Inc. DAC08AQ Digital-to-Analog Converter

The DAC08AQ from Analog Devices Inc. is a high-performance, 8-bit digital-to-analog converter (DAC) that offers exceptional accuracy and stability. This monolithic DAC is designed for applications where a stable and reliable digital-to-analog conversion is essential, such as in precision instrumentation, digital control systems, and automated test equipment.

Featuring a fast-settling output and a full-scale current output of 1 mA with an external output resistor, the DAC08AQ is capable of converting an 8-bit binary input into an analog output with high precision. The device operates from a single power supply ranging from +4.5V to +15.5V or a dual power supply of ±4.5V to ±15.5V, providing flexibility in various system designs.

One of the key advantages of the DAC08AQ is its ease of interfacing with microprocessors and digital systems. It employs a double-buffered, single-buffered, or flow-through digital data input structure, which allows for simple and efficient data handling. The input logic levels are TTL and CMOS compatible, ensuring seamless integration with a wide range of digital systems.

In addition to its high performance, the DAC08AQ is also characterized by its reliability and robustness. It features a high output drive capability and built-in short-circuit protection, making it a dependable choice for critical applications. The device is packaged in a compact 16-pin plastic DIP (PDIP) or SOIC, suitable for space-constrained applications.

Overall, the DAC08AQ is a versatile and reliable solution for digital-to-analog conversion needs. Its high-speed operation, combined with its precision and ease of use, makes it an excellent choice for designers looking to enhance the performance of their analog systems.

For detailed specifications, application notes, and support resources, users can visit the Analog Devices Inc. website or contact their technical support team for further assistance.
