Product Overview: LT1117CM#PBF

The LT1117CM#PBF is a versatile and reliable fixed voltage regulator designed by Analog Devices Inc., a leader in semiconductor technology. This product is part of the LT1117 series, which are known for their low dropout performance and ease of use in a wide range of applications. The LT1117CM#PBF is specifically engineered to provide a stable output voltage with a low dropout voltage, making it an ideal choice for systems where voltage supply stability is critical.

Key Features

• Low Dropout Voltage: The LT1117CM#PBF boasts a low dropout voltage, which ensures efficient operation even when the input voltage is close to the output voltage, thus maximizing battery life in portable applications.
• Adjustable Output: While the device can be configured to provide a fixed output, it also offers the flexibility to adjust the output voltage to meet specific requirements using external resistors.
• High Output Current: Capable of delivering up to 800mA of continuous output current, this voltage regulator can power a wide range of devices and circuits.
• Thermal Protection: The LT1117CM#PBF is equipped with thermal overload protection that safeguards the device and the system in high-temperature conditions.
• Current Limiting: A built-in current limit feature helps protect the regulator and the load from overcurrent conditions.

Applications

The LT1117CM#PBF is highly versatile and can be used in various applications such as:

• Power supplies for battery-powered devices
• Post-regulation for switching power supplies
• Microprocessor supply
• Linear power regulators for embedded systems

Quality and Reliability

Analog Devices Inc. ensures that the LT1117CM#PBF meets the highest quality and reliability standards. The device is available in a TO-263 package, which is known for its robustness and excellent thermal performance. With its advanced design and built-in protection features, the LT1117CM#PBF is a dependable choice for engineers and designers looking for a stable power solution.
