LT6015HS5#TRPBF

Part No LT6015HS5#TRPBF
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 1 CIRCUIT TSOT23-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 37 Weeks
Features General Purpose Amplifier 1 Circuit Rail-to-Rail TSOT-23-5
Manufacturer Analog Devices Inc.
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C
Mounting Surface Mount
Package SOT-23-5 Thin, TSOT-23-5
Case / Package TSOT-23-5
Family Name LT6015
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.33.0001
Other Part Number LT6015HS5#TRPBF-ND, LT6015HS5#TRPBFCT, LT6015HS5#TRPBFDKR, LT6015HS5#TRPBFTR
Quantity per package 2500
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 878859-LT6015HS5#TRPBF
Ultra Librarian 3D Model Ultra Librarian LT6015HS5#TRPBF CAD Model

Description

Analog Devices Inc. LT6015HS5#TRPBF Operational Amplifier

The LT6015HS5#TRPBF is a high-performance operational amplifier from Analog Devices Inc., designed to offer precision and stability in a variety of applications. This particular model comes in a compact SOT-23 package, making it suitable for space-constrained applications where performance cannot be compromised. Its robust design ensures operation under tough conditions, making it a reliable choice for industrial, automotive, and instrumentation applications.

With its wide supply voltage range of 3.1V to 30V, and the capability to operate in single or split-supply configurations, the LT6015HS5#TRPBF offers designers flexibility in various circuit designs. This op-amp boasts a low input offset voltage, low input bias current, and a high gain-bandwidth product, ensuring high accuracy and fast response times in feedback control systems and sensor interfaces.

The LT6015HS5#TRPBF features a low input offset voltage that typically stands at 80µV, with a maximum of 300µV over the entire temperature range. Its input bias current is also remarkably low, typically 5nA, which is especially beneficial for high-impedance sensor applications. The device's gain-bandwidth product is 3.2MHz, allowing for a wide range of frequencies to be accurately amplified without significant signal degradation.

This operational amplifier is designed to withstand harsh environments. It can operate across a wide temperature range of -40°C to 125°C, which is essential for automotive and industrial applications where temperature extremes are common. Additionally, the LT6015HS5#TRPBF features Over-The-Top® protection, enabling it to handle inputs up to 76V above the negative supply without damage, which is a significant advantage in environments where voltage spikes and surges are a concern.

For applications that demand precision and durability, the LT6015HS5#TRPBF from Analog Devices Inc. is an excellent choice. Its combination of high accuracy, robust protection features, and small form factor makes it a versatile component for engineers looking to create reliable and high-performing electronic systems.

To ensure optimal performance and quality, the LT6015HS5#TRPBF is provided in tape and reel packaging, denoted by the 'TRPBF' suffix, which facilitates automated assembly processes, making it suitable for high-volume production.
