The LT8301HS5#TRPBF is a high-performance, monolithic, micropower step-up DC/DC converter from Analog Devices Inc. This compact and efficient component is designed to be a part of various applications, especially those requiring a small footprint and minimal power loss. It is an ideal solution for battery-powered devices, as well as for energy harvesting systems, due to its low quiescent current and high efficiency.

Key Features

• Integrated 42V, 0.5A Switch: The LT8301HS5#TRPBF comes with an integrated 42V/0.5A switch, which allows it to handle a wide range of input and output voltages, making it versatile for numerous applications.
• Wide Input Voltage Range: This converter operates over a wide input voltage range from 3V to 100V, accommodating a variety of power sources.
• High Efficiency: With its high efficiency, the LT8301HS5#TRPBF can deliver a significant amount of power without wasting energy, which is critical for portable and battery-operated devices.
• Low Quiescent Current: It features a low quiescent current under 7µA, ensuring minimal power drain when in standby mode.
• Fixed Frequency Operation: The device operates at a fixed 2MHz frequency, allowing the use of small, low-cost capacitors and inductors while avoiding critical noise-sensitive frequency bands.

Applications

The LT8301HS5#TRPBF is suitable for a wide range of applications, including but not limited to:

• Battery-Powered Equipment
• Energy Harvesting Systems
• Industrial Power Supplies
• Wall Transformer Regulation
• Automotive and Avionics Power Systems

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability. The LT8301HS5#TRPBF is built to meet high standards, ensuring stable performance and longevity in the field. It is available in a thermally enhanced SOT-23 package, which provides excellent power dissipation and space efficiency on the circuit board.

Ordering Information

The LT8301HS5#TRPBF is available for order in tape and reel packaging, denoted by the suffix 'TRPBF', which facilitates automated assembly processes. For detailed ordering and shipping information, refer to the Analog Devices Inc. official website or contact their sales and support team.
