PTV05010WAD Emerson Network Power
Same model may have multiple batches, images only for reference.

PTV05010WAD

Part No PTV05010WAD
Manufacturer Artesyn Embedded Technologies
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 0.8-3.6V 28.8W
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Artesyn Embedded Technologies
Series PTV05010 (28W)
Package Tray
Product Status Active
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 5.5V
Voltage - Output 1 0.8 ~ 3.6V
Current - Output (Max) 8A
Power (Watts) 28.8 W
Applications ITE (Commercial)
Features Remote On/Off, OCP, UVLO
Temperature Range - Operating -40°C ~ 85°C
Efficiency 95%
Mounting Type Through Hole
Package / Case 8-SIP Module
Size / Dimension 0.90" L x 0.33" W x 0.40" H (22.9mm x 8.4mm x 10.2mm)
Base Product Number PTV05010
Standard Package 84 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 658014-PTV05010WAD
Ultra Librarian 3D Model Ultra Librarian PTV05010WAD CAD Model

Description

The PTV05010WAD is a non-isolated PoL module manufactured by Artesyn Embedded Technologies. It is part of the PTV05010 series, which is a 28W power supply designed for board mount applications in the power supplies category.

  • Size: 0.90" L x 0.33" W x 0.40" H
  • Power Output: 28.8W
  • Maximum Output Current: 8A
  • Input Voltage Range: 4.5V to 5.5V
  • Output Voltage Range: 0.8V to 3.6V
  • Protection: Remote On/Off, Over Current Protection (OCP), and Under Voltage Lockout (UVLO)
  • Efficiency: 95%
  • Mounting Type: Through-Hole
  • Package: 8-SIP
  • Application: ITE (Commercial)
