The 100B470JW500XT is a high-performance single layer ceramic capacitor manufactured by ATC (American Technical Ceramics). It is designed for demanding RF and microwave applications that require high Q, low ESR, and stable performance over a wide temperature range. This capacitor belongs to the ATC 100B series, which is known for its ultra-stable performance and reliability.

Applications:

• RF Power Amplifiers
• Microwave Circuits
• Wireless Communication Systems
• Satellite Communication
• Filter Networks
• Matching Networks
• Medical Electronics
• High-Frequency Tuning
• Test and Measurement Equipment

Features:

• High Q-factor: Ensures low losses and efficient performance in RF circuits.
• Low ESR (Equivalent Series Resistance): Minimizes power dissipation and improves circuit efficiency.
• High Self-Resonant Frequency (SRF): Allows for use in high-frequency applications without significant performance degradation.
• Ultra-Stable Performance: Provides consistent and reliable operation over a wide range of temperatures and frequencies.
• Single Layer Construction: Offers superior performance compared to multilayer capacitors in high-frequency applications.
• High Voltage Rating: Suitable for high-power RF applications.
• RoHS Compliant

Benefits:

• Improved Circuit Performance: High Q and low ESR contribute to more efficient and stable RF circuit operation.
• Increased Reliability: Ultra-stable performance ensures consistent and dependable operation over time.
• Suitable for High-Frequency Applications: High SRF allows for use in demanding RF and microwave designs.
• Reduced Power Consumption: Low ESR minimizes power dissipation, improving overall system efficiency.
• Compact Size: Allows for use in space-constrained applications.

Specifications:

The 100B470JW500XT has a capacitance value of 47pF. It is a single-layer ceramic capacitor with a voltage rating of 500V. Its physical dimensions are typically very small, designed for surface mount applications. It is constructed from high-quality ceramic materials to provide excellent stability and performance. The operating temperature range is typically -55°C to +125°C. The termination is typically gold or tin-plated for excellent solderability.
