DFA20E24S12 Power-One
Same model may have multiple batches, images only for reference.

DFA20E24S12

Part No DFA20E24S12
Manufacturer Bel Power Solutions
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 12V 20W
Datasheet
DFA20E24S12 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Bel Power Solutions
Series DFA20
Package Bulk
Product Status Obsolete
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 18V
Voltage - Input (Max) 36V
Voltage - Output 1 12V
Current - Output (Max) 1.7A
Power (Watts) 20 W
Voltage - Isolation 700 V
Applications ITE (Commercial)
Features Remote On/Off, OCP, OTP, SCP
Temperature Range - Operating -40°C ~ 85°C
Efficiency 83%
Mounting Type Through Hole
Package / Case 7-DIP Module
Size / Dimension 2.02" L x 2.02" W x 0.45" H (51.3mm x 51.3mm x 11.4mm)
Control Features Enable, Active High
Standard Package 125 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 584519-DFA20E24S12
Ultra Librarian 3D Model Ultra Librarian DFA20E24S12 CAD Model

Description

The 584519-DFA20E24S12 is a DC-DC converter module designed for power supplies in ITE (Commercial) applications.

  • Series: DFA20
  • Module Type: Isolated
  • Power: 20W
  • Efficiency: 83%
  • Size: 2.02" L x 2.02" W x 0.45" H (51.3mm x 51.3mm x 11.4mm)
  • Package: 7-DIP Module
  • Voltage Isolation: 700V
  • Output Count: Single
  • Output Voltage: 12V
  • Output Current: 1.7A
  • Input Voltage Range: 18V to 36V
  • Operating Temperature: -40°C to 85°C
  • Manufacturer: Bel Power Solutions
  • Standard Package: 125 pcs
  • ECCN: EAR99
  • REACH: Unaffected
