SDE0403A-180M Real Image
Same model may have multiple batches, images only for reference.

SDE0403A-180M

Part No SDE0403A-180M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SDE0403A-180M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE0403A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 18 µH
Tolerance ±20%
Current Rating (Amps) 750 mA
Current - Saturation (Isat) 1.1A
Shielding Unshielded
DC Resistance (DCR) 309mOhm Max
Frequency - Self Resonant 28MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.177" L x 0.157" W (4.50mm x 4.00mm)
Height - Seated (Max) 0.138" (3.50mm)
Base Product Number SDE0403A
Other Names SDE0403A-180MDKR,SDE0403A-180MCT,SDE0403A-180MTR
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274935-SDE0403A-180M
Ultra Librarian 3D Model Ultra Librarian SDE0403A-180M CAD Model

Description

The Bourns SDE0403A-180M is a wirewound drum core inductor designed for use in various electronic circuits.

  • Package Size: 4.50mm x 4.00mm
  • Inductance: 18 µH
  • Maximum DC Resistance: 309mOhm
  • Current: 750mA
  • Tolerance: ±20%
  • Core Material: Ferrite
  • Self-Resonant Frequency: 28MHz
  • AEC-Q200: Rated
  • Suitable for: Automotive applications
  • Packaging: Tape and Reel
  • Standard Package: 2,000
