Same model may have multiple batches, images only for reference.
SRF0703A-150M Real Image
Same model may have multiple batches, images only for reference.

SRF0703A-150M

Part No SRF0703A-150M
Manufacturer Bourns Inc.
Catalog Arrays, Signal Transformers
Datasheet
SRF0703A-150M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Arrays, Signal Transformers
Mfr Bourns Inc.
Series SRF0703A
Package Tape & Reel
Number of Coils 2
Inductance - Connected In Parallel 15 µH
Inductance - Connected In Series 59.6 µH
Tolerance ±20%
Current Rating - Parallel 1.83 A
Current Rating - Series 916 mA
Current Saturation - Parallel 2.05 A
Current Saturation - Series 1.03 A
DC Resistance (DCR) - Parallel 119mOhm Max
DC Resistance (DCR) - Series 470mOhm Max
Shielding Shielded
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.299" L x 0.299" W (7.60mm x 7.60mm)
Height 0.142" (3.60mm)
Base Product Number SRF0703A
Other Names 118-SRF0703A-150MDKR,SRF0703A-150MCT,SRF0703A-150MTR,118-SRF0703A-150MTR,SRF0703A-150MCT,SRF0703A-150MTR,SRF0703A-150MDKR,118-SRF0703A-150MCT,SRF0703A-150MDKR
Standard Package 1,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1275005-SRF0703A-150M
Ultra Librarian 3D Model Ultra Librarian SRF0703A-150M CAD Model

Description

The Bourns Inc. SRF0703A is a shielded inductor array designed for signal transformers.

  • Package: Tape and Reel
  • Standard Package: 1,500
  • Height: 0.142"
  • Number of Coils: 2
  • Inductance (Series): 59.6 µH
  • Inductance (Parallel): 15 µH
  • Current Rating (Parallel): 1.83 A
  • Current Rating (Series): 916 mA
  • Current Saturation (Parallel): 2.05 A
  • Current Saturation (Series): 1.03 A
  • DC Resistance (DCR) (Parallel): 119mOhm max
  • DC Resistance (DCR) (Series): 470mOhm max
  • Package/Case: Non-standard
  • Temperature Range: -40°C to 125°C
  • Dimension: 0.299" L x 0.299" W (7.60mm x 7.60mm)
  • Rating: AEC-Q200
  • ECCN: EAR99
  • MSL: 1 (unlimited)
  • REACH: Unaffected
  • HTSUS: 8504.50.4000
