Same model may have multiple batches, images only for reference.

PDB181-K420K-103B

Name: PDB181-K420K-103B
Brand: Bourns Inc.
SKU: 888823
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PDB181-K420K-103B
Manufacturer	Bourns Inc.
Catalog	Rotary Potentiometers, Rheostats
Description	POT 10K OHM 1/5W CARBON LINEAR / 10k Ohm 1 Gang Linear Panel Mount Potentiometer None 1.0 Kierros Carbon 0.2W, 1/5W PC Pins
Datasheet	PDB181-K420K-103B Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Potentiometers, Variable Resistors - Rotary Potentiometers, Rheostats
Mfr	Bourns Inc.
Series	Pro Audio PDB18
Package	Bulk
Product Status	Active
Resistance (Ohms)	10k
Tolerance	±20%
Power (Watts)	0.2W, 1/5W
Built in Switch	None
Number of Turns	1
Taper	Linear
Number of Gangs	1
Adjustment Type	Side Adjustment
Rotation	300°
Resistive Material	Carbon
Termination Style	PC Pins
Actuator Type	Knurled and Slotted
Actuator Length	0.787" (20.00mm)
Actuator Diameter	0.236" (6.00mm)
Bushing Thread	M7 x 0.75
Mounting Type	Panel Mount
Size - Body	Round - 0.669" Dia (17.00mm)
Base Product Number	PDB181
Standard Package	75 pcs
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8533.40.8070
California Prop 65	Warning Information
Win Source Part Number	888823-PDB181-K420K-103B
Ultra Librarian 3D Model	Ultra Librarian PDB181-K420K-103B CAD Model

Alternative Products

Description

The PDB181-K420K-103B is a rotary potentiometer from Bourns Inc. The PDB181-K420K-103B is a rotary potentiometer from Bourns Inc.

Type: Rotary Potentiometer
Taper: Linear
Resistance: 10k Ohms
Tolerance: ±20%
Power Rating: 0.2W
Adjustment: Side Adjustment
Gang: Single
Rotation Angle: 300°
Bushing Thread: M7 x 0.75
Body Size: 0.669" diameter (17.00mm)
Mounting: Panel Mounting
Termination: PC Pins
Operating Temperature: -40°C to 125°C
Application: Audio
