ACMD-6003-TR1 Broadcom Limited ACMD-6003-TR1 label picture
Same model may have multiple batches, images only for reference.
ACMD-6003-TR1 Broadcom Limited ACMD-6003-TR1 label picture
ACMD-6003-TR1 Broadcom Limited ACMD-6003-TR1 label picture
Same model may have multiple batches, images only for reference.

ACMD-6003-TR1

Part No ACMD-6003-TR1
Manufacturer Broadcom Limited
Catalog Hard To Find
Description High Isolation | RF DUPLEXER 1.75/1.84GHZ 8VQFN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Tape and Reel
Status Obsolete
Type Duplexer
Frequency Bands (Low / High) 1.71GHz ~ 1.79GHz / 1.8GHz ~ 1.88GHz
Low Band Attenuation (min / max dB) 45.00dB / 60.00dB
High Band Attenuation (min / max dB) 40.00dB / 62.00dB
Return Loss (Low Band / High Band) 9.5dB / 9.5dB
Mounting Style SMD
Manufacturer Package 8-VQFN Exposed Pad, CSP
Manufacturer Pack Quantity 3,000
MSL Level 3 (168 Hours)
Win Source Part Number 1135280-ACMD-6003-TR1
Manufacturer Homepage www.avagotech.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ACMD-6003-TR1 CAD Model

Description

The Broadcom Limited Duplexer is a high-performance electronic component that is designed to separate signals in a transmission line.

  • Category: RF/IF and RFID
  • Status: Obsolete
  • Package: Tape and Reel
  • Manufacturer Pack Quantity: 3,000
  • MSL Level: 3 (168 Hours)
