HCPL-314J-500E Real Image HCPL-314J-500E real image
Same model may have multiple batches, images only for reference.
HCPL-314J-500E Real Image HCPL-314J-500E real image
HCPL-314J-500E Real Image HCPL-314J-500E real image
Same model may have multiple batches, images only for reference.

HCPL-314J-500E

Part No HCPL-314J-500E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description OPTOISO 5KV 2CH GATE DRIVER 16SO / Optocoupler Drive Push-Pull 2-CH 30V 1500V 16-Pin SOIC T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Technology Optical Coupling
Number of Channels 2
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 700ns, 700ns
Rise and Fall Time 50ns, 50ns
Current - Output High, Low 500mA, -
Current - Peak Output 600mA
Forward Voltage 1.5V
Continuous forward current- Max 25mA
Supply Voltage - Operating 10 V to 30 V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SO
Approvals CSA, IEC/EN/DIN, UR
Win Source Part Number 016871-HCPL-314J-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 850
Family Name HCPL-314J
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Singapore, Thailand
Halogen Free Not Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian HCPL-314J-500E CAD Model

Description

The Broadcom Limited 149181 is an optical coupling isolator.

  • Win Source Part Number: 016871-HCPL-314J-500E
  • Packaging: Reel - TR
  • Technology: Optical Coupling
  • Number of Channels: 2
  • Common Mode Transient Immunity: 25kV/μs
  • Mounting: SMD (SMT)
  • Temperature Range: -40°C to 100°C
  • Popularity: High
  • Supply and Demand: Balanced
  • Quantity per Package: 850
