HCPL-M600-500E Real Image HCPL-M600-500E real image4581
HCPL-M600-500E Real Image HCPL-M600-500E real image4581
Same model may have multiple batches, images only for reference.

HCPL-M600-500E

Part No HCPL-M600-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description Optocoupler Logic-Out Open Collector DC-IN 1-CH 5-Pin SOIC T/R / OPTOISO 3.75KV OPN COLLECTOR 5SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 10kV/μs (Typ)
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.5V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 5-SO
Win Source Part Number 091252-HCPL-M600-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 1,500
Family Name HCPL-M600
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Singapore, Philippines
Halogen Free Not Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCPL-M600-500E CAD Model

Description

The Broadcom Limited 091252-HCPL-M600-500E is a single-channel optoisolator that is part of the optoisolators - transistor, photovoltaic output family. The device provides high isolation voltage and high-speed data transmission.

  • Data Rate: 10MBd
  • Common Mode Transient Immunity: 10kV/μs (Typ)
  • Package: 5-SO
  • Popularity: High
