CP336V-2N5551-CT20 Real Image
Same model may have multiple batches, images only for reference.

CP336V-2N5551-CT20

Part No CP336V-2N5551-CT20
Manufacturer Central Semiconductor Corp
Catalog Transistors (BJT) - Single
Description TRANS NPN 1=20PCS
Datasheet
CP336V-2N5551-CT20 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Central Semiconductor Corp
Packaging Tray
Status Active
Transistor Polarity NPN
Maximum Current Collector 600mA
VCEO Maximum Collector-Emitter Breakdown Voltage 160V
Max Vce (sat) 200mV @ 5mA, 50mA
Collector Cut-off Current(Max) 50nA (ICBO)
Typical Gain (hFE) (Min) 80 @ 10mA, 5V
Frequency - Transition 300MHz
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package Die
Win Source Part Number 1003952-CP336V-2N5551-CT20
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CP336V-2N5551-CT20 CAD Model

Description

The CP336V-2N5551-CT20 is an NPN Transistor manufactured by Central Semiconductor Corp.

  • Maximum Collector-Emitter Breakdown Voltage: 160V
  • Maximum Collector Current: 600mA
  • Frequency Transition: 300MHz
  • Collector Cut-off Current: 50nA
  • Typical Gain (hFE): 80 @ 10mA, 5V
  • Packaging: Die
  • Operating Temperature: -65°C to 150°C
  • Vce (sat): 200mV @ 5mA, 50mA
  • Category: Discrete Semiconductor Products
