The CY7C199-35PC is a high-performance CMOS static RAM (SRAM) manufactured by Cypress Semiconductor. It's organized as 32,768 words by 8 bits. This SRAM is designed for applications requiring fast access times and ease of use with its asynchronous operation.

Applications

• Embedded systems
• Cache memory
• Buffer memory
• Microprocessor systems
• Data acquisition systems

Features

• High speed: 35 ns access time
• Low active power: Typically 110 mA
• Low standby power: Typically 10 mA
• Single 5V power supply
• Fully static operation: no clock or refresh required
• TTL-compatible inputs and outputs
• Available in 28-pin DIP and SOIC packages

Benefits

• Fast access times allow for quick data retrieval and processing, improving system performance.
• Low power consumption reduces energy costs.
• Static operation simplifies system design and eliminates the need for complex refresh circuitry.
• TTL-compatible inputs and outputs ensure compatibility with a wide range of digital logic devices.
• The DIP and SOIC packages provide flexibility for different board mounting requirements.

Technical Specifications

The CY7C199-35PC SRAM has a typical access time of 35 ns. It operates from a single 5V power supply. The active current consumption is typically 110 mA, while the standby current consumption is typically 10 mA. The device is available in 28-pin DIP and SOIC packages. It features fully static operation, meaning that no clock or refresh signals are required to maintain data integrity. It uses standard TTL-compatible inputs and outputs.

Package Information: 28-pin DIP and SOIC

Operating Voltage: 5V
