The AH286-YL-13 is a high-performance, precision Hall Effect latch from Diodes Incorporated, renowned for its reliability and efficiency in a wide range of applications. This device is specifically designed to detect magnetic fields and provide a digital output that indicates the presence of a magnetic field with either north or south polarity.

Key Features

• High Sensitivity: The AH286-YL-13 is capable of detecting low-level magnetic fields, making it suitable for applications that require accurate sensing capabilities.
• Temperature Resistant: It operates reliably over a wide temperature range, ensuring stable performance in varying environmental conditions.
• Chopper Stabilized: The Hall Effect latch includes a chopper-stabilized design that provides a stable operation over its full operating range, reducing signal drift and enhancing accuracy.
• Low Power Consumption: Designed for energy efficiency, this device is an excellent choice for battery-powered applications where power conservation is critical.
• Output Polarity Indication: The output signal indicates the polarity of the detected magnetic field, making it straightforward to integrate into various control systems.

Applications

The AH286-YL-13 is versatile and can be used in numerous applications including, but not limited to:

• Brushless DC motor control
• Position and speed sensing
• Magnetic encoders
• Flow meters
• Proximity detection

Product Specifications

The AH286-YL-13 comes in a compact SOT-23 package, which is suitable for surface-mount technology (SMT) and occupies minimal space on a printed circuit board (PCB). It operates within a supply voltage range of 3.5V to 20V, making it compatible with a wide range of power sources and systems. The device also includes an open-drain output, which simplifies interfacing with other circuit components.

Quality and Reliability

Diodes Incorporated is committed to delivering high-quality products. The AH286-YL-13 is built to meet stringent industry standards, ensuring long-term reliability for critical applications. Customers can trust this Hall Effect latch to perform consistently in their designs.
