AP7313-33SRG-7

Part No AP7313-33SRG-7
Manufacturer Diodes Incorporated
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 3.3V 0.15A 3-Pin SOT-23 T/R / IC REG LDO 3.3V 0.15A SOT23R-3
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Diodes Incorporated
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 6V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 0.3V @ 150mA
Output Current 150mA
Operating Supply Current 75μA to 85μA
PSRR 65dB (100Hz)
Control Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 85°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 0.15V @ 150mA
Mounting SMD (SMT)
Case / Package SOT-23R-3
Win Source Part Number 010111-AP7313-33SRG-7
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AP7313
Introduction Date August 20, 2009
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian AP7313-33SRG-7 CAD Model

Description

Diodes Incorporated AP7313-33SRG-7 Voltage Regulator

The AP7313-33SRG-7 is a highly efficient, low dropout voltage regulator designed by Diodes Incorporated, a leading manufacturer in the semiconductor market. This component is specifically engineered to deliver a fixed output voltage of 3.3V with an input voltage range from 3.5V to 24V, making it an ideal choice for a wide range of electronic applications that require a stable and reliable power supply.

One of the standout features of the AP7313-33SRG-7 is its low dropout voltage, which ensures minimal voltage loss between the input and output, thereby improving overall system efficiency. This is particularly beneficial in battery-operated devices where maximizing battery life is critical. The device is capable of delivering an output current of up to 150mA, which is sufficient for low-power applications such as microcontrollers, sensors, and other integrated circuits.

The AP7313-33SRG-7 comes in a compact SOT-23 package, which is highly favored for space-constrained applications. Its small footprint allows for integration into compact PCB designs without sacrificing performance. Additionally, the device features over-current protection and thermal shutdown mechanisms that safeguard the system against excessive current and overheating, respectively.

With its low quiescent current, the AP7313-33SRG-7 is also an excellent choice for portable and wearable devices, as it minimizes power consumption during idle periods, thereby extending the operating life of the product. Moreover, the regulator's high ripple rejection ratio ensures that the output voltage remains stable even in the presence of input voltage fluctuations, which is crucial for maintaining the performance of sensitive electronic components.

In summary, the AP7313-33SRG-7 from Diodes Incorporated is a reliable and efficient voltage regulator that offers a fixed 3.3V output, low dropout, and robust protection features. Its small size and low power consumption make it an optimal solution for a variety of applications where space and energy efficiency are of paramount importance.

For detailed specifications and application notes, designers and engineers are encouraged to consult the datasheet and technical documentation provided by Diodes Incorporated.
