Product Overview: AP8802SPG-13 LED Driver IC

The AP8802SPG-13 is a high-performance, constant current LED driver IC manufactured by Diodes Incorporated, a leading global manufacturer and supplier of high-quality application-specific standard products within the broad discrete, logic, analog, and mixed-signal semiconductor markets. This integrated circuit is specifically designed to efficiently drive strings of up to eight series-connected LEDs from a voltage source ranging from 6V to 30V.

With its integrated 30V power MOSFET, the AP8802SPG-13 is capable of delivering a precise, constant current to ensure uniform brightness in lighting applications. The current can be set via an external resistor, providing designers with flexibility and control over the lighting characteristics. This feature makes the AP8802SPG-13 an ideal choice for a wide range of applications, including backlighting, signage, decorative lighting, and general-purpose LED illumination.

Key Features and Benefits

• High Efficiency: The device features up to 97% efficiency, which helps to minimize power loss and heat generation, leading to more reliable and long-lasting LED solutions.
• Thermal Protection: Built-in thermal shutdown protection ensures that the device operates within safe temperature limits, preventing damage to the IC and the LEDs it controls.
• Wide Input Voltage Range: With an operating range of 6V to 30V, the AP8802SPG-13 is versatile and can be used in various applications with different power supply requirements.
• Constant Current Output: The ability to provide a stable current enhances the consistency of LED brightness and color, which is crucial for applications where light quality is important.
• PWM Dimming Capability: The device supports pulse-width modulation (PWM) dimming, allowing for adjustable brightness levels, which can be particularly useful in creating dynamic lighting effects or reducing power consumption.
• Simple Application Circuit: The AP8802SPG-13 requires minimal external components, which simplifies the design and reduces the overall bill of materials.

The AP8802SPG-13 comes in a compact SOP-8 package, making it suitable for space-constrained applications. Its robust design and comprehensive feature set make it a highly reliable and efficient solution for driving high-brightness LEDs.

Whether you're developing commercial lighting systems, portable lighting solutions, or custom LED arrays, the AP8802SPG-13 from Diodes Incorporated offers the performance and ease of use needed to create high-quality, energy-efficient lighting applications.
